French Fry Fryer

Equipment Introduction

The french fry fryer is specially designed for root tuber products. It is available in several structural forms, including single?pot batch, dual?pot alternating, and continuous mesh belt automatic fryers, meeting the production needs of different scales.

This series of french fry fryers adopts advanced oil layer heating technology, equipped with an efficient circulation filtration system to ensure constant frying temperature (±1℃), giving french fries and chips uniform color and a crispy texture. The built?in anti?stick mesh belt and forced pressing device thoroughly solve the problems of floating and sticking, while significantly improving frying oil utilization. It is suitable for the industrial continuous production of potato fries, sweet potato fries, cassava fries, and various chips. With high automation, energy saving and environmental protection, it is an ideal choice for frozen french fry factories and snack food enterprises.

Equipment Composition

Equipment Features

1. The main body is made of high?quality SUS304 food?grade stainless steel with adequate thickness, robust and corrosion?resistant, complying with national food safety and hygiene standards and meeting the high hygiene requirements of french fry processing.

2. The unique double?layer mesh belt with pressing device completely submerges the french fries in oil, ensuring even heating on all sides, solving floating and uneven frying problems, and producing a uniformly golden color.

3. Equipped with an efficient dynamic oil residue filtration system that continuously separates fine debris produced during frying, greatly extending oil life and reducing oil consumption per ton by 25%.

4. Fully automatic PLC control system with PID temperature control module ensures precise temperature within ±1℃. Preset process curves for different raw materials (potato / sweet potato / cassava) are available, and multiple safety devices such as over?temperature protection and low?oil alarm enable continuous, safe production.

5. Special anti?stick mesh belt with food?grade non?stick coating ensures french fries do not stick or break, increasing finished product integrity by 15%.

Technical Parameters

Working Principle

Frying principle: Heat is transferred to the frying oil via a burner (gas/oil) or electric heating tubes, rapidly raising the oil temperature to the set value (typically 165-185℃). Pretreated french fries enter the hot oil via a conveyor belt, where surface moisture quickly boils away, enabling rapid cooking, coloring, and formation of a crispy crust. A special pressing mesh belt fully submerges the fries, ensuring uniform heating. Fine debris is removed by the oil circulation filtration system, and clean oil returns to the tank, ensuring stable oil quality during continuous operation and keeping the oil clear.

Production Results

Frying Effect
